Mitutoyo Series 514 Vernier Hight Gauge

The Mitutoyo Series 514 Vernier Height Gauge is a precision mechanical measuring instrument designed for accurate height measurement, marking out and dimensional inspection in engineering and manufacturing environments.

Featuring an adjustable main scale, the Series 514 allows the zero reference point to be repositioned for convenient measurement. The satin chrome-finished main and vernier scales provide clear, glare-resistant readings, while the large base offers excellent rigidity and stability during use.

A fine adjustment mechanism allows precise positioning of the measuring slider, and the carbide-tipped scriber supplied as standard provides accurate marking out on workpieces.

Available in a range of measuring capacities, the Mitutoyo Series 514 is ideal for inspection rooms, machine shops and precision engineering applications.

Key Features:

  • Mitutoyo Series 514 mechanical vernier height gauge.

  • Adjustable main scale for repositioning the zero reference point.

  • Satin chrome-finished scales for glare-free reading.

  • Large base for improved rigidity and stability.

  • Fine adjustment mechanism for precise positioning.

  • Carbide-tipped scriber supplied as standard.

  • Optional magnifier available for easier scale reading.

  • Available in metric and metric/inch models.

  • Measuring ranges f

There are no downloads for this product.

There are no reviews for this product yet. Be the first to add one!

Code Description Price Quantity
12-1052T Mitutoyo 514-103 300mm/12" Vernier Height Gauge
£362.40 (exc VAT)
Save £90.60 (List £453.00)
12-1052TA Mitutoyo 514-105 450mm/18" Vernier Height Gauge
£693.60 (exc VAT)
Save £173.40 (List £867.00)
12-1052TB Mitutoyo 514-107 600mm/24" Vernier Height Gauge
£920.00 (exc VAT)
Save £230.00 (List £1,150.00)
12-1052TC Mitutoyo 514-109 1000mm/40" Vernier Height Gauge
£2,032.00 (exc VAT)
Save £508.00 (List £2,540.00)
